Project's Description

Design of amphitheatrical lecture room - scientific library and artificial kidney unit wings and addition of a new storey nursing unit at the existing building of the Lamia General Hospital. The extension compirises four new, structurally independent reinforced concrete buildings. Addition of a new storey and strengthening of the existing interdepartmental walkway. Combination of shallow and deep foundation. Berlin type retaining structure. The biggest building consists of three storeys and one basement with rectangular plan, measuring 35 m in length. The second bigger building has two storeys and circular plan, measuring 16 m in diameter.

Moreover, the design of the secondary steel bearing structures for the suspension of surgical lights and robotic arms under the existing concrete roof of the Lamia General Hospital surgery rooms has been realized.

Project's Details

• Client: PLUS MEDICA Ltd / LAMIA GENERAL HOSPITAL
• Design Stages: Preliminary and Detailed Design, Tender Documents
• Budget (Structural): 1,600,000 €
• Design Period: 2007
• Project State: The project has not put been put out to tender yet due to lack of funding
• Architectural Design: BETAPLAN S.A.
• MEP Design: TRIEDROS S.A.
